Customizable MK400GS Centerless Grinding Machine
Grinding Wheel Spindle: double-support sleeve structure
Control System: siemens 828D
Processing Mode: fully automatic
Precision: high precision
Certification: GS, CE, ISO 9001
Customisation: upon request
Place of Origin: Wuxi, China
Machining Accuracy Grade: P4/P5
External Dimensions: 2600mm*1700mm*2000mm
MOQ: 1 set
DM: 4 months
Packaging: three-ply board
MK400GS centerless grinder machining accuracy
NO. | Item | Required Precision |
1 | Resiplus (including deformation error) | 0.08-0.12 mm (diameter direction) |
2 | Divergence (before grinding) | 0.025 mm |
3 | Ellipticity (grinding grinding) | 0.005m m |
4 | Roundness (before grinding) | 1.2um |
5 | Dispersion (after grinding) | 0～0.005 mm |
6 | Roundness (2~15 waves) (after grinding) | 0.8μm |
7 | Surface Roughness Ra (after grinding) | 0.32μm |
8 | Conical Degree (after grinding) | 0.002 mm |
Product characteristics and performance
Features and performance of this machine tool：Strong rigidity, high precision, can be used for bearing ring through grinding and shaft type other multi-step cutting grinding, the machine tool has high precision, high degree of automation, high production efficiency
The machine tool has two models:
1, Siemens 828D numerical control system + servo motor + ball screw control.
2, Siemens 828D numerical control system + linear motor + optical control.
3, the guide wheel and grinding wheel are using double support structure, high dimensional accuracy after grinding, roundness, roughness, system accuracy resolution of 0.1um, low failure rate.
4, the grinding wheel, the guide wheel only needs to set the data according to the requirements, which can automatically repair the shape of the requirements, safe and reliable.
5, the machine tool has a self-diagnosis function with text display alarm, the system has a powerful protection function.
Other specifications
Machine Model | Grinding Diameter (mm) | Grinding Whee Specifications (mm) | Working Accuracy | Tota Power (kw) | Weight (kg) | Overal Dimensions (cm) | Remarks | |
Roundness | Consistency Odiameter | |||||||
MK200GS | 10～100 | P500×400×305 | 2 | 3/5（Cut in） | 32 | 4000 | 272×135×170 | High precision, CNC |
MK400GS | 10～100 | PSA300×100×127 | 2 | 3/5（Cut in） | 42 | 7000 | 272×135×170 | Wide grinding wheel, CNC |
